Standard models for flow rates from 1.0 to 50 m3/hr.
Exchange capacities from 1.0kg to 75kg as CaCO3.
Choice of regeneration control systems manual or automatic by time, time store and water meter.
Control options use the latest technology.
All models designed for simplex, duplex or multiple unit operation.
Standard units have twin pistons automatic actuator control valve in corrosion resistant polypropylene and PVC Valve provides full 5-cycles regeneration and has manual override.
12 or 24 VAC operation for maximum safety.
Units are easy to install & operation require minimum maintenence.
Full service backup, installation and commissioning services available.
Customized units can be supplied for higher flow rates.

Standard models for flow rate from 0.5 m3/hr to 45.0 m3 /hr
Exchange capacities for Cation from 1.2 kg to 62 kg as CaC03
Exchange capacities for Anion from 0.5 kg to 25.3 kg as CaC03
Choice of regeneration control systems manual or automatic by time store,water meter and conductivity.
Control options use the latest technology.
All models designed for simplex,duplex or multiple unit operation.
Standard units have twin piston automatic multiport control valve in corrosion resistant polypropylene and PVC valve provides full 5 cycle regeneration and has manual overide
12 VAC operation for maximum safety
Units are easy install & operate.
Require minimum maintenance.
Full service backup, installation and commissioning service available.
Customized units can be supplied for higher flow rates.

Standard models for flow rates from 0.5 m3/hr to 65.0 m3/hr.
Exchange capacities from 0.34kg to 15.5kg.
Choice of regeneration control systems manual or automatic by water meter and conductivity.
Control options use the lastest technology.
All models designed for simplex, duplex or multiple unit operation.
Control by programmable logic controller through individual control valves of corrosion resistant glass reinforced ABS material.
Vessel constructed of mild steel internally rubber lined.
Customized units can be supplied for higher flow rates.

Series commercial & industrial reverse osmosis systems are designed for a wide variety of water purification applications production capacity ranges until 1.0 to 100 m3/hr depending on the model and membrane type.

Standard Features
Thin film, brackish water membrane
Pre micron filter 5 microns
Stainless steel high pressure pump
FRP pressure vessels (300 psi)
Concentrate/Recirculation/
Permeate flowmeter
Low/High pressure protection
Pressure guage for pre filter
Pressure guage for high pressure
Conductivity monitoring
Automatic flushing
Control panel with PLC system
Carbon steel skid mounted

Optional Features
316 SS Housing cartridge
316 SS High pressure pump
pH monitoring
Antiscale dosing pump/dosing tank
Acid dosing pump/dosing tank
CIP cleaning system

---
